We are exporting Container Metal Shear from the ports of Shanghai, Qingdao, Tianjin, Ningbo. We can arrange for FOB shipping and TT payment. We can offer Container Metal Shear at the most cost-effective prices on the market. We are able to supply the Container Metal Shear to any global location within the specified time frame. We can offer Container Metal Shear on 120000/USD pricing term.
Please contact us with your required number of quantity, if you are interested in purchasing our Container Metal Shear. We can export Container Metal Shear Machine globally and looking for genuine buyers.
Our company, Acesun Heavy Industry Co., Ltd. has grown into a professional manufacturer of all types of scrap metal recycling industry, waste recycling industry, metallurgy, sanitation, mould, and agricultural equipment after years of experience and development.
1.Introduction
We supply all kinds of scrap metal recycling machines with big and small production. Use baler to compress scrap to get higher density bales, Horizontal Metal Shear to cut big scraps into small pieces. with shredding line you can get pure and high quality charging for furnace smelting. One stop shopping to buy all what you need.
2.Features
1. Increased safety. When the box shears work, the materials are always in the chamber, and there is no danger of material splashing.
2. Increase production efficiency and save labor costs. The container shears are fully automated, with suction cups or steel grabs for feeding, requiring only one person to operate, increasing work efficiency and saving labor costs.
3.can be moved. The container shears are designed with the integration of the whole machine in mind, enabling on-vehicle movement, allowing users to process waste at different sites, saving a lot of transportation costs.
3.Specifications
No. CS-4000 Horizontal Metal Shear Technical Data
1 Cutting Cylinder Model YG320/220-1000 Stroke 1000mm
Nominal force 2000KN×2 Qty 2pcs
2 Pressing cylinder Model YG250/160-750 Stroke 750mm
Nominal force 1200KN Qty 1pcs
3 Chamber size(L×W×H) 2400×1400×1985 (mm)
4 Feeding size(L×W×H) 3400×2400×900(mm)
5 Dimension(L×W×H) 7000*2300*3200(mm)
6 Working pressure 21.5Mpa
7 Cutting blade length 1400mm
8 Cutting height 400mm
9 Cutting frequency 3times/min
10 Production 5~8T/h
11 Cooling type Plate water cooling
12 Operation mode Manual/Auto/
Remote control/PLC
13 Total weight 25.5T
14 Total Power 74KW
15 Cutting material size db=440N/mm2 Round steel:f100mm
Square steel:100×100mm
L-bar:180×180×15mm
I-beam:320×132×11.5mm
16 Motor Model Y250M-6 Power 37kw
Speed 980rpm Qty 2sets
17 Oil pump Model HY250Y-RP Pressure 31.5Mpa
Flow 250ml/r Qty. 2sets
4.Applications
Horizontal Metal Shear is Applicable in recycling companies, automobile dismantling plants, smelting & casting industry to cold-shear section steel and metallic structural parts into acceptable size furnace charges.
Horizontal Metal Shear is used for economical scrap processing, easy operation and flexible transportation with a roll on/roll off system. Various models for your choice.
5.Advantages
1. Independent research and development, independent brand, national patent, mature technology
2. Imported parts, lower operating costs, higher quality, energy efficient
3. Fully enclosed structure, high safety performance and low probability of work injury
4. There is a vehicle-mounted mobile customization to meet the needs of the replacement site
5. Integrated installation free, ready to use
6. PLC control, automatic hand operation, automatic labor free
7. Power system and diesel system are two-pronged, for one choice
8. Cycle design, long working hours and low human capital requirements
9. Wide application range, less material delivery restrictions, high safety performance
10. Independent design, long service life and large shearing force
