Eddy Current Separator ECC 104 X – 2 Meter Wide
1 / 3
Product Brochures
1 DocumentBM 104X Eccentric Eddy Current Separator – Product BrochurePDF
Product brochure featuring the Bakker Magnetics BM 104X Eccentric Eddy Current Separator, including its key features, technical specificatio...
Complete Machine Specifications
| Brand | Bakker Magnetics |
| Model Number | BM 104X |
| Machine Type | New Machine |
| Category | General |
| Subcategory | Separators |
| Location | Basel, Basel-Stadt, Switzerland |
| Manufacturing Year | 2025 |
| Country of Origin | Switzerland |
| Power Source | Electric |
| Weight | 2500 KG |
| Material Type | Metal Frame |
| Automation Grade | Fully Automatic |
| Motor Power | AC Motor |
| Specifications | The Bakker Magnetics BM 104X Eccentric Eddy Current Separator is a high-speed magnetic separation system designed for the efficient separation of ferrous and non-ferrous metals. It features an electronically adjustable rotor speed and offers a processing capacity of up to 6–8 tons per hour. Machine Type: Eccentric Eddy Current Separator Model: BM 104X Machine Width: 2000 mm (2 Meter) Capacity: Up to 6–8 tons/hour Rotor Type: High-speed eccentric magnetic rotor Pole Frequency: Extremely high pole frequency Maximum Field Frequency: 1.56 kHz Maximum Rotor Speed: Up to 3,600 RPM Minimum Fraction Size: 0.5 mm Motor: 4 kW + 9.2 kW SEW engines Mechanism: Self-cleaning mechanism Magnetic System: High number of magnetic poles Construction: Sturdy construction Design: Modular design Particle Handling: Separation of ferrous and non-ferrous metals with a high volume output per hour Available Widths: 800 / 1000 / 1500 / 2000 mm Machine Length: 5490 mm Rotor Type: High-speed eccentric magnetic rotor Rotor Speed: Up to 3,600 RPM Rotor Speed Adjustment: Electronically adjustable Separating Shield: Electric separating shield for precise positioning of the separating plate. |
| Usage / Application | The Bakker Magnetics BM 104X Eccentric Eddy Current Separator is designed for efficient separation and recovery of ferrous and non-ferrous metals from mixed material streams. It is suitable for recycling and material processing applications, particularly for separating fine and very fine particles. With an adjustable rotor speed and a capacity of up to 6–8 tons per hour, the system is designed for efficient metal separation and recovery. |
| Listed On | 31/08/2026 |
